Ef435 Four Wheel Drive Rough Terrain Forklift 3.5ton
Basic Info
Model NO. | EF435 Forklift |
Certification | CE |
Condition | New |
Warranty | 1 Year |
Load Center Distance | 500 Tmm |
Overhang | 350 mm |
Front Overhang | 495.5 mm |
Wheelbase | 1800 mm |
Transport Package | Standard Export Package or as Your Required |
Specification | Total length 2174mm; Total width 1080mm |
Trademark | China Coal Group |
Origin | Shandong, China |
Production Capacity | 1000 Sets Per Month |
Product Description
Introduction of EF435 Four Wheel Drive Rough Terrain Forklift 3.5ton
Due to its simple and flexible operation and control, the operating intensity of electric forklifts is much lighter than that of internal combustion forklifts. Its electric steering system, acceleration control system, hydraulic control system and brake system are all controlled by electric signals, which greatly reduces In this way, the labor intensity of the operator is greatly improved, which is very helpful to improve the work efficiency and accuracy of the work. Compared with internal combustion forklifts, the advantages of low noise and no exhaust emissions of electric vehicles have also been recognized by many users.zmwm02
In addition, there are some technical reasons for choosing electric forklifts. The rapid development of electronic control technology makes the operation of electric forklifts more and more comfortable, the wider the scope of application, and the more and more solutions to logistics. From these aspects, the market demand for electric forklifts will definitely grow faster and faster, and the market share of electric forklifts will also become larger and larger.
Parameters of EF435 Four Wheel Drive Rough Terrain Forklift 3.5ton
Characteristic | Rated lifting weight | kg | 3500 | |
Load center distance | mm | 500 | ||
Overhang | mm | 350 | ||
Front overhang | mm | 495.5 | ||
Wheelbase | mm | 1800 | ||
total weight (No load With battery) | kg | 5350 | ||
Size | Total length (To vertical surface of fork) | mm | 2595 | |
Total width | mm | 1274 | ||
Height of overhead guard | mm | 2140 | ||
Standard mast height that does not rise | mm | 2120 | ||
Standard mast Maximum stretch height | mm | 4080 | ||
Maximum fork height (Rated lifting weight) | mm | 3000 | ||
Standard mast inclination( Leanforward/Reclining) | deg | 7/7 | ||
Ground clearance of frame | mm | 130 | ||
Standard mast Free lifting height | mm | 140 | ||
Turning radius (Smallest outside) | mm | 145 | ||
Mlinimum theoretical width of right-anglechannel | mm | 2280 | ||
Minimum theoretical width of right-anglestacking channel | mm | 2340 | ||
Fork pitch range | mm | 4280 | ||
The smallest x The largest | mm | 250X1100 | ||
Performance | Maximum travel speed (No load) | Km/h | 19/17.5 | |
Lifting speed (fully loaded/No load) | Mm/s | 450/550 | ||
speed of decent(fully loaded/No load) | Mm/s | 500/500 | ||
Largest traction(fully loaded/No load) | N | 17650/16500 | ||
Maximum grade (fully loaded) | % | 20 | ||
Tires | Front wheel | 23x9-10 | ||
Rear whee1 | 18x7-8 | |||
Power system | battery(1ithium optiona1) | Voltage | V | 80 |
Capacitance | ah | 400-720 | ||
Rated power of wa1king motor | Kw/rpm | 2x7.5 | ||
Rated power of 1ifting motor | Kw/rpm | 23.5 | ||
Control1er form | AC |
Photos of EF435 Four Wheel Drive Rough Terrain Forklift 3.5ton
